The MP-165 I-V tracer (MTI.AWS.EK.165) is the optimum solution for testing individual solar cell or module characteristics in combination with a solar simulator or natural sunlight. It can be found in factory quality control applications or long-term performance assessment studies of modules exposed to natural conditions outdoors.

The cell or module performance characteristics are determined by changing the electrical load during the I-V sweep. The radiant energy on the module can be measured simultaneously with the voltage and current measurements to calculate to Standard Test Conditions (STC) or equivalent standards. The MP-165 can take samplings of voltage, current, and solar irradiance at the same time.

It can also take measurements with an artificial light source (sequential illumination). Connecting the MP-165 to a computer using an RS-232C connector allows the measured data to be displayed graphically.

MP-165 I-V Tracer

SKU: MTI.AWS.EK.165

• Measurement range voltage : 0.05 to 400 V

• Measurement range current : 0.005 to 20 A

• Measurement range power : 0 to 3000 W

• Voltage range : 30 V / 400 V

• Voltage resolution : 0.05 µV (V)

• Current range : 3 A / 20 A

• Current resolution : 0.005 A

• Sweep time : 2 to 330 Sec

• Accuracy : ± 0.5°C

• Data points : 256

• Data storage internal memory PC

• Operating temperature range 0 to 40°C

• Communication RS-232

• Power supply 100 to 240 VAC, 270W

• Dimensions mm 450 (W) x 450 (D) x 199 (H)

• Weight : 15 kg

• Ingress protection IP : -

• Input channels : 1
